2023 Naval Yachts

XPM

78' / 23.77m

Builder Naval Yachts

Classification CE A Open Unrestricted

Naval Architect & Exterior Styling Michael Schutte

Interior Design Karine Rousseau

LOA 23.90 m.

Displacement 65 t.

LWL 21.6 m.

Fuel capacity 7000 litres

Beam 10.1 m.

Fresh Water Capacity 1200 litres

Draft 1.0 m.

Watermaker 2400 liters/day

Speed 14 kts

Construction Material Marine Grade Aluminium

Range @ 10kts 1.200 nm

Main Deck:

Master Cabin 01: Queen Size Bed, 55’’ smart TV 3D sound, Couch and Wadrobe

Master Cabin 02: Queen Size Bed, 55’’ smart TV 3D sound, Couch, and Wardrobe

Galley: Miele Microwave Convection Combo, Miele Cooktop, Miele Hood, Custom Fridge & Freezer, Fagor Washer/Dryer Combo, Fisher & Paykel Dishdrawer x2, Hettich Dropdown Cabinets x3, Bose Ipod SoundDock

Owner Office: Computer Work Station

Day Head: Planus Vacuum Toilet

Lower Deck:

VIP Suite (2+1): 32’’ Smart TV, Blu-ray DVD player, Bose Ipod SoundDock, En süite toilet & shower, His and Hers sinks

Twin Suite (2+1):

26’’ TV, Blu-ray DVD Player, Bose Ipod SoundDock, En Suite Toilet & Shower

Engines 2 x JD- 425 hp

Gear Boxes Twin Disc

Steering Wills Ridley Hydraulic Steering with back-up

Bowthruster Side Power

Main Generator Cummins Onan 20 KVA (Optional)

Electrical System 110/208 60Hz 3 Phase

Shore Power 20 Kw

Batteries 50 kWh Firefly Carbon Foam Batteries, Victron Emergency Batteries, Firefly Carbon Foam Service Batteries

Air Conditioning Marvair 70000 BTU w/2 stage chiller

Other Machinery Tender Davits 1t capacity

Diesel Engines: JOHN DEERE 575HP x 2 diesel engines and Twin Disc Gearbox. This configuration gives better performance and extra safety. JD Engines have a worldwide service network, easy-to-find spare parts, and are known as low-maintenance engines. The cruise speed is 9 knots and the Maximum speed of the vessel is 14 Knots.

Parallel Hybrid Propulsion (Optional): 50kw x 2 e-motors + 200 kwh Lithium batteries controlled by an electro-mechanical clutch. E-Motors work as a Genset while diesel engines are running. 28 nautical miles range on electric motors at 7 knots. No smell, no exhaust, no noise, fuel efficiency, fuel saving, free access to extra sensitive and protected environments, and many other features.

Solar Power: 50 sqm solar panel area which generates 12,5 kw/hour. If considered as 6 hours of efficient sunlight in a day; the solar panels generate 75 kw/day which is not only enough for a house load but also enough to load the Lithium batteries.

4 Cabins Layout: 2 Master Cabins + 2 VIP Cabins+ 1 Crew Cabin Enormous Areas in Saloon and the Aft Deck: Saloon has been designed explicitly by keeping its outstanding stability performance and nice look. Saloon height and inner volumes height have been also raised. In the saloon, the ceiling is 5 mt. (16 ft.) high and it has an inside balcony with a panoramic view of the saloon. There is a huge aft deck area and two swim platforms where you can enjoy your time with your family and friends.

Steering System: Wills Ridley Brand from the U.K. has been applied. Independent rudder control for dynamic positioning system accuracy and maneuverability. An easy valve operation for keeping rudders in sync while using a manual helm pump. Both pumps and cylinders have a backup for safety.

Dynamic Positioning System (Optional):

Two independent rudder control systems, a larger bow thruster, and the control unit make the boat positioned in the same position without an anchor. Another innovative approach on XPM boats.

Communication: Furuno FM8800 VHF Radiophone, Furuno FA 50 AIS Transponder, Intellion Vsat-80, Jacop Jensen Telephones, Wireless and Wifi Access Points

Navigation: Furuno VHF NX700B with Active Antenna, Furuno SC30 Satellite Compass w/NMEA Interface, Humphree Interceptor System, Furuno DFF1 Echo Sounder Navget, Furuno DRS4A15 Radar, Simrad AC12 Autopilot Computer with AP28 Display, 3x17’’ Hatteland Display Monitors, Furuno 1kW 200 kHz Transducer on Port, Furuno 1 kW 50 kHz transducer on Starboard Foredeck Equipment

Advanced Navigation, Automation, and Alarm Systems: All controls and monitoring of systems are on one system with additional backup configurations. Integrated helm station and ship MIMIC diagrams covering nav and all machinery plus ship alarms, CCTV, horn, and nav light arrays.

Advanced Safety Systems for MCA Compliance (Optional): MCA Certification requires many safety regulations and they are pretty strict but makes the boat super safe. By getting MCA cert. The XPM78 will be proven about safety concerns. Also, MCA enables commercial chartering licenses worldwide.

Certification: All XPM boats are certified with CE A Open Class and MCA (optional) through internationally approved institutions.

Equipment with worldwide services: Our main goal is to go far and to go everywhere with any XPM boat. All XPM equipment is equipped by worldwide known and certified brands. They are all proven products and worldwide service networks. In long passages, no matter where the boat is, any technical problem with equipment and systems can be fixed quickly and any spare part can be found easily.
